Votatec Slim Linkable T5 LED Fixtures
Shop Votatec slim integrated T5 LED fixtures for under-cabinet lighting, shelving, displays, workbenches, counters, closets, workshops, utility spaces, retail installations, and continuous linked-lighting layouts across Canada.
The Votatec linkable T5 family is available in 0.5-foot, 1-foot, 2-foot, 3-foot, and 4-foot lengths. Each fixture offers selectable 3000K, 4000K, and 5000K colour temperatures, dimming capability, and a slim one-inch-wide profile.
Where to Use Votatec Linkable T5 Fixtures
Under-Cabinet Task Lighting
Slim fixtures provide focused illumination for kitchen counters, work surfaces, utility counters, cabinets, and preparation areas.
Shelving & Display Lighting
Link multiple fixtures for retail shelves, showcases, product displays, bookcases, storage systems, and commercial merchandising.
Workshops & Utility Spaces
Use T5 fixtures above workbenches, tool areas, closets, storage rooms, garages, service spaces, and maintenance stations.
Votatec Linkable T5 Model Family
Compact 6-inch fixture for short cabinets, narrow shelves, display niches, small work areas, and tightly spaced lighting layouts.
VO-T5FIXW3FT0.5-120-3WAY-S-DProduct page in development
Twelve-inch fixture for under-cabinet task lighting, shelves, displays, closets, work areas, and linked installations.
VO-T5FIXW5FT1-120-3WAY-S-D23.7-inch fixture for longer cabinet runs, shelving, retail displays, workshops, closets, and service counters.
VO-T5FIXW9FT2-120-3WAY-S-DProduct page in development
35.6-inch fixture for extended work surfaces, shelving runs, utility areas, workshops, and commercial display applications.
VO-T5FIXW13FT3-120-3WAY-S-DProduct page in development
47.5-inch fixture for long counters, workbenches, storage areas, utility rooms, continuous runs, and commercial task lighting.
VO-T5FIXW18FT4-120-3WAY-S-DProduct page in development
Votatec T5 Fixture Specifications
| Model | Nominal Length | Actual Length | Power | Lumen Output | Maximum Linked Fixtures |
|---|---|---|---|---|---|
| VO-T5FIXW3FT0.5-120-3WAY-S-D | 0.5 ft | 6 in | 3W | 250 lm | 26 |
| VO-T5FIXW5FT1-120-3WAY-S-D | 1 ft | 12 in | 5W | 500 lm | 16 |
| VO-T5FIXW9FT2-120-3WAY-S-D | 2 ft | 23.7 in | 9W | 900 lm | 9 |
| VO-T5FIXW13FT3-120-3WAY-S-D | 3 ft | 35.6 in | 13W | 1300 lm | 6 |
| VO-T5FIXW18FT4-120-3WAY-S-D | 4 ft | 47.5 in | 18W | 1800 lm | 4 |
Shared Electrical & Lighting Specifications
120V / 60Hz input, approximately 100 lm/W efficacy, CRI greater than 80, power factor 0.9, 135° beam angle, and dimmable operation.
Shared Construction & Performance
Approximately 1 inch wide and 0.6 inches high, selectable 3000K / 4000K / 5000K, operating range from approximately −20°C to +45°C, cUL listed, and rated for 50,000 hours.
Votatec T5 Linking Accessories
Power Cord
Separate power-cord option identified for selected 1-foot and 2-foot fixture installations.
Fixture-to-Fixture Connecting Cable
Separate connecting cable for spacing fixtures apart while maintaining a linked lighting run.
3.93ft Power Cord with Plug
Plug-in power cord with a male linking end for selected portable or cord-connected installations.
Wire Box with Female End & Switch
Separate wire box with a female connection and on/off switch for selected hardwired installations.
Compatible Dimmer Models Listed by Votatec
| Dimmer Brand | Compatible Model |
|---|---|
| Lutron | DVCL-153PLH |
| Leviton | 6681 |
| Lutron | S600-P |
| Lutron | DV600-P15 |
| Leviton | 6674 |
| MACL | 153M |
| Lutron | PD-6WCL |
How to Plan a Linkable T5 Lighting Run
Measure the Full Installation Area
Measure cabinet, shelf, counter, or workbench length and account for gaps, corners, obstructions, and cable-routing space.
Select the Best Fixture Combination
Combine 0.5ft, 1ft, 2ft, 3ft, and 4ft fixtures to create the required coverage while staying within the maximum linked quantity.
Choose Direct Linking or Cable Linking
Fixtures can be linked directly or separated using compatible connecting cables, depending on cabinet breaks, shelves, corners, and layout requirements.
Confirm Power & Control Method
Determine whether the project requires a plug-in cord, hardwired switch box, compatible wall dimmer, local on/off control, or another approved connection method.
Explore the Votatec Product Ecosystem
Votatec Linkable T5 Lighting FAQ
What sizes are available in the Votatec slim T5 family?
The family includes nominal 0.5-foot, 1-foot, 2-foot, 3-foot, and 4-foot fixtures, with actual lengths of approximately 6, 12, 23.7, 35.6, and 47.5 inches.
What colour temperatures are available?
Each fixture provides selectable 3000K, 4000K, and 5000K colour temperatures.
How many fixtures can be linked together?
The manufacturer lists maximum linked quantities of 26 for the 3W model, 16 for 5W, 9 for 9W, 6 for 13W, and 4 for 18W. Do not exceed the stated limit for the selected model.
Are Votatec T5 fixtures dimmable?
Yes. Votatec lists the family as dimmable and provides a compatible dimmer list. Confirm the latest dimmer guidance and total connected load before installation.
Are the connecting cables and power cords included?
Some power and linking accessories are identified as separately sold items. Confirm the package contents and required accessories for the exact model and installation.
Does MarsLED ship Votatec T5 fixtures across Canada?
MarsLED supports online orders and project inquiries across Canada. Shipping availability, rates, and timing depend on destination, fixture length, order quantity, and inventory.
