Votatec VO-WPRW120-347-3WAY-BA 120W CCT, Power & Beam Angle Adjustable Regular LED Wall Pack

Save 25%

Price:
$224.98 $300
**Promotion Terms & Conditions Apply. MARS Lighting & Electrical Supplies reserves the right to modify or cancel this offer at any time. Cannot be combined with any other promo/discounts/offer. Contact our in-store sales associate for details. *Minimum order quantities may be required to qualify for this promotional price. Offer valid till stocks last or 12/31/2026. Limited Quantities in stock, Orders fulfilled on First Come First Serve basis. Conditions Apply. All Promotional Sales considered as Final Sales. No Exchange No Returns.

Description

Votatec Beam-Angle Adjustable Wall Pack

Votatec VO-WPRW120-347-3WAY-BA 120W CCT, Power & Beam Angle Adjustable Regular LED Wall Pack

The Votatec VO-WPRW120-347-3WAY-BA is an upgraded commercial regular LED wall pack for building exteriors, loading areas, service doors, rear entrances, walkways, perimeter walls, parking areas, and outdoor security lighting where selectable beam distribution is required.

This bronze wall pack supports 120W / 100W / 80W / 60W power selection, 3500K / 4000K / 5000K CCT selection, T2 / T3 / T4 beam-angle adjustment, 120-347V input, built-in photocell operation, 0-10V dimming, IP65 wet-location use, DLC Premium approval, glass lens construction, and a 5-year warranty.

120W / 100W / 80W / 60W7,858-16,452 Lumens3500K / 4000K / 5000KT2 / T3 / T4 Beam120-347VBuilt-In PhotocellIP65 Wet LocationDLC Premium

Why Choose This Beam-Angle Adjustable Wall Pack?

Selectable Beam Distribution

The T2 / T3 / T4 beam-angle adjustment helps match the fixture to walkways, entrances, parking edges, perimeter walls, and wider exterior coverage areas.

CCT + Power Adjustable

Select 120W, 100W, 80W, or 60W and choose 3500K, 4000K, or 5000K on site to match the required light level and colour temperature.

Photocell + Dimming

The built-in photocell and 0-10V dimming driver support dusk-to-dawn operation and project-based lighting control.

Verified Product Specifications

Brand Votatec
SKU VO-WPRW120-347-3WAY-BA
Fixture Type CCT + power + beam angle adjustable regular LED wall pack with built-in photocell
Input Voltage AC120-347V
Wattage 120W / 100W / 80W / 60W adjustable
Lumen Output 7,858-16,452 lm depending on selected wattage, CCT, and beam setting
Colour Temperature 3500K / 4000K / 5000K adjustable
CRI Ra 70 / >70
Beam / Distribution T2 / T3 / T4 adjustable
Rated Life 50,000 hours
Operating Frequency 50/60Hz
Power Factor ≥0.9
Dimming 0-10V dimming driver
Surge Protection L-N: 4kV; L,N-GND: 6kV
Lens Material Glass lens
Housing ADC12 + glass / die-cast aluminum cooling design
Housing Colour Bronze
Dimensions 14.20" L × 9.40" W × 7.50" H
Weight 7.05 lb
Operating Temperature -40°C to 45°C / -40°F to 113°F
IP Rating IP65
IK Rating IK08
Location Rating Wet location
Photocell Built-in photocell with on/off function
Mounting Wall mount
Rated For Enclosed Fixture Yes
DLC Approved Yes, DLC Premium
Warranty 5 years
Project note: This beam-angle adjustable wall pack is suitable for commercial exterior wall-lighting applications where selectable beam distribution, selectable wattage, selectable CCT, photocell control, and 120-347V input are required.

Lumen Output by Setting

Setting 3500K 4000K 5000K
120W 15,876 lm 16,452 lm 15,612 lm
100W 13,230 lm 13,710 lm 13,010 lm
80W 10,584 lm 10,968 lm 10,408 lm
60W 7,938 lm 8,226 lm 7,806 lm

Best Applications

Building Exteriors

Use for exterior walls, entrances, rear doors, service doors, and general commercial wall-mounted security lighting.

Parking & Perimeter Areas

Suitable for parking-lot edges, perimeter walls, wider exterior zones, walkways, and controlled wall-mounted security lighting.

Loading & Service Areas

A good choice for loading doors, service yards, receiving areas, utility entrances, and back-of-building locations.

Beam-Sensitive Projects

The T2 / T3 / T4 selection helps reduce overstocking and gives installers flexibility when distribution needs vary by wall location.

Related Votatec Wall Packs & Exterior Lighting

For the standard regular wall pack, see the Votatec VO-WPRW120-347-3WAY Regular Wall Pack. For compact wall-pack applications, see the Votatec VO-MWP30W Mini Wall Pack. For full cut-off lighting, see the Votatec WP10-120M-PSC-3CCT Full Cut-Off Wall Pack. Browse the full Votatec Commercial & Industrial Lighting collection.

Product Resources

Frequently Asked Questions

What is the Votatec VO-WPRW120-347-3WAY-BA?

It is a 120W CCT, power, and beam-angle adjustable regular LED wall pack with selectable 120W / 100W / 80W / 60W power, selectable 3500K / 4000K / 5000K colour temperature, T2 / T3 / T4 beam adjustment, AC120-347V input, built-in photocell, 0-10V dimming, IP65 wet-location rating, and DLC Premium approval.

What does BA mean on this wall pack?

BA refers to the beam-angle adjustable version. This model supports T2, T3, and T4 beam selection.

Is this wall pack power adjustable?

Yes. This model supports 120W, 100W, 80W, and 60W selectable power settings.

Is this LED wall pack CCT adjustable?

Yes. The fixture supports 3500K, 4000K, and 5000K selectable colour temperature.

Does this regular wall pack have a photocell?

Yes. The specification sheet lists a built-in photocell with on/off function.

Can this wall pack be used outdoors?

Yes. The specification sheet lists IP65 and wet-location use.

Need Votatec Beam-Angle Adjustable Wall Packs for a Project?

Contact MarsLED for stock checks, contractor quantities, project pricing, and exterior wall-lighting recommendations for building exteriors, service doors, loading zones, walkways, parking edges, and security lighting.
