Votatec VO-LHW220FT4-10Y-347-3WAY-S 4FT Linear High Bay LED Light 220W Adjustable 120-347V 3CCT - 10Yr Warranty

Save 14%

Price:
$249.98 $290
**Promotion Terms & Conditions Apply. MARS Lighting & Electrical Supplies reserves the right to modify or cancel this offer at any time. Cannot be combined with any other promo/discounts/offer. Contact our in-store sales associate for details. *Minimum order quantities may be required to qualify for this promotional price. Offer valid till stocks last or 12/31/2026. Limited Quantities in stock, Orders fulfilled on First Come First Serve basis. Conditions Apply. All Promotional Sales considered as Final Sales. No Exchange No Returns.

Description

Votatec 4FT Linear High Bay

Votatec VO-LHW220FT4-10Y-347-3WAY-S 4FT Linear High Bay LED Light - 10Year Warranty

The Votatec VO-LHW220FT4-10Y-347-3WAY-S is a 4 foot linear high bay LED light designed for warehouses, workshops, industrial units, storage facilities, garages, gyms, production areas, and commercial high-ceiling spaces.

This adjustable 120-347V linear high bay provides 220W / 160W / 110W selectable power, 3500K / 4000K / 5000K selectable colour temperature, 0-10V dimming, 120 degree beam angle, 10kV surge protection, damp location rating, IP20 rating, cUL listing, DLC 5.1 Premium rating, and included chain, V-hook, and wire cap for suspension mounting.

4FT Linear High Bay120-347V220W / 160W / 110W16500-33000LM3CCT Selectable0-10V Dimming10kV SurgeDLC 5.1 Premium

Why Choose This 4FT Votatec Linear High Bay?

High-Output 4FT Design

The 4 foot body and 220W maximum power setting make this fixture suitable for larger bays, wider fixture spacing, and high-output commercial lighting layouts.

Power Adjustable

Select 220W, 160W, or 110W output to match ceiling height, fixture spacing, energy target, and project lighting requirements.

120-347V Commercial Input

The 120-347V input range supports many commercial and industrial electrical environments where voltage flexibility is important.

Verified Product Specifications

Brand Votatec
SKU VO-LHW220FT4-10Y-347-3WAY-S
Fixture Type 4 foot linear high bay LED light
Length 4FT
Input Voltage 120-347V
Wattage 220W / 160W / 110W adjustable
Nominal Lumen Output 33,000 lm / 24,000 lm / 16,500 lm listed
Tested Lumen Output Up to 33,475 lm depending on selected wattage and CCT
Colour Temperature 3500K / 4000K / 5000K adjustable
CRI 80
Beam Angle 120 degrees
Dimming 0-10V dimming
Rated Life 50,000 hours
Operating Frequency 50/60Hz
Power Factor >0.9
Surge Protection 10kV
Operating Position Vertical only
Operating Temperature -40°F to 113°F
Housing Colour White
Net Weight 6.64 kg / 14.64 lb
Dimensions 45.67" L x 14.17" W x 2.89" H
IP Rating IP20
Location Rating Damp location
Safety Listing cUL
DLC Rating DLC 5.1 Premium
Included Accessories Chain / V-Hook / Wire cap
Optional Accessories PIR sensor, remote control, surface mount kit, pendant kit, emergency option
Warranty 5 years listed in catalogue/vendor documents unless otherwise confirmed by Votatec
Catalogue Carton Qty 1
Warranty note: The SKU contains “10Y,” but the June 2026 catalogue row and the current vendor linear high bay tech sheet show 5-year warranty language. Confirm with Votatec before advertising this as a 10-year warranty product.

Lumen Output by Setting

Power Setting 3500K 4000K 5000K
110W 18,300 lm 18,862.2 lm 18,015.3 lm
160W 24,961.2 lm 26,810.2 lm 24,987.2 lm
220W 31,270.4 lm 33,475 lm 31,462.7 lm
Output note: Catalogue output is listed as 16,500-33,000 lumens. Tested lumen output varies by selected wattage and colour temperature.

Best Applications

Warehouses & Distribution Spaces

Use for open warehouse areas, logistics spaces, storage buildings, racking aisles, loading areas, and high-ceiling lighting upgrades.

Workshops & Industrial Units

Suitable for fabrication shops, service bays, repair spaces, maintenance areas, production areas, and industrial work zones.

Commercial Garages & Service Bays

A strong option for automotive bays, contractor garages, fleet service spaces, utility buildings, and work areas requiring higher light output.

Gyms & Multi-Purpose Facilities

Use in approved gymnasiums, recreational spaces, training areas, and other larger high-ceiling interiors.

Related Votatec High Bay Products & Accessories

For the standard 4FT version, see the Votatec VO-LHW220FT4-347-3WAY-D-S 4FT Linear High Bay LED Light. For the smaller 2FT version, see the Votatec VO-LHW160FT2-347-3WAY-D-S 2FT Linear High Bay LED Light. Browse the full Votatec Commercial & Industrial Lighting collection.

Product Resources

Frequently Asked Questions

What is the Votatec VO-LHW220FT4-10Y-347-3WAY-S?

It is a 4 foot Votatec linear high bay LED light with adjustable wattage, selectable colour temperature, 120-347V input, 0-10V dimming, 10kV surge protection, and included chain, V-hook, and wire cap.

What wattages are selectable?

The fixture supports 220W, 160W, and 110W adjustable power settings.

What colour temperatures are selectable?

The fixture supports 3500K, 4000K, and 5000K adjustable colour temperature settings.

Is this high bay dimmable?

Yes. The vendor tech sheet lists 0-10V dimming.

What is the voltage range?

The vendor tech sheet lists 120-347V input voltage.

Does this have a 10-year warranty?

The SKU includes “10Y,” but the catalogue row and vendor tech sheet show 5-year warranty language. Confirm warranty terms with Votatec before treating it as a 10-year warranty product.

Need Votatec 4FT Linear High Bays for a Project?

Contact MarsLED for stock checks, contractor quantities, lighting-layout support, sensor accessories, mounting options, and commercial project pricing.
