CSC LED LHB04-220W-3P-3CCT-UD-WH White Linear High Bay Wattage and CCT Selectable

Economisez 15%
Eligible for Save on Energy Instant Discounts (Ontario)

Rebates applied instantly on your MarsLED invoice for qualifying commercial, industrial & institutional customers in Ontario.

filler

Prix:
$219.94 $260
**Promotion Terms & Conditions Apply. MARS Lighting & Electrical Supplies reserves the right to modify or cancel this offer at any time. Cannot be combined with any other promo/discounts/offer. Contact our in-store sales associate for details. *Minimum order quantities may be required to qualify for this promotional price. Offer valid till stocks last or 12/31/2025. Limited Quantities in stock, Orders fulfilled on First Come First Serve basis. Conditions Apply. All Promotional Sales considered as Final Sales. No Exchange No Returns.

Description

CSC LED LHB04-220W-3P-3CCT-UD – White Linear High Bay (Wattage & CCT Selectable)

Description

The CSC LED LHB04-220W-3P-3CCT-UD is a high-performance linear LED high bay designed for warehouses, industrial facilities, gymnasiums, and commercial spaces with higher ceiling heights. With power-selectable and CCT-selectable settings, it delivers maximum flexibility for both new construction and retrofit projects.

  • Power selectable: multiple wattage options up to 220W in a single fixture.
  • Colour selectable: 3000K / 4000K / 5000K for customized visual comfort.
  • High efficacy LED design for excellent lumen output and reduced hydro costs.
  • Low-profile linear form factor ideal for aisles, racking, and open industrial spaces.
  • 0–10V dimmable driver with universal voltage (120–347V).
  • Durable housing and lens suitable for demanding commercial and light industrial environments.
  • Save on Energy eligible – suitable for Ontario rebate programs when used in qualifying applications.

Typical Applications

  • Warehouses and distribution centres
  • Manufacturing and production areas
  • Big-box retail and wholesale stores
  • Gymnasiums and recreation centres
  • Commercial storage and back-of-house areas

Light Performance

  • Wattage: up to 220W (power-selectable levels in one fixture)
  • CCT options: 3000K / 4000K / 5000K (3CCT selectable)
  • High lumen output suitable for medium to high mounting heights
  • High colour rendering for improved visibility and safety
  • Designed for even, low-glare illumination in aisles and open areas

Electrical Specifications

  • Voltage: 120–347V (universal driver)
  • Dimming: 0–10V dimmable
  • High power factor and low THD for clean, efficient operation
  • Long LED life rating for reduced maintenance and fewer relamps

Construction & Mounting

  • Linear high bay housing with robust metal construction.
  • White finish (WH) for clean, professional appearance.
  • Impact-resistant lens designed for uniform light distribution.
  • Suitable for chain, cable, or other high bay mounting methods (check CSC LED spec sheet for details).

Save on Energy Rebate Eligibility

This fixture is an excellent candidate for Save on Energy Instant Discounts in Ontario when installed in qualifying commercial or industrial applications. Mars Lighting & Electrical (MarsLED) can help you:

  • Confirm eligibility based on your facility type and operating hours.
  • Select the right wattage and CCT setting for your space.
  • Apply instant rebates directly on your MarsLED invoice for qualifying projects.

To confirm rebate eligibility and build a complete lighting package, please request an energy audit or rebate-eligible quote.

Looking for more CSC LED fixtures? Visit our CSC LED Brand Page or browse the CSC LED Product Collection.


Why Choose CSC LED?

CSC LED is a trusted Canadian LED lighting manufacturer known for high-performance commercial and industrial fixtures. Mars Lighting & Electrical is an authorized CSC LED distributor supporting contractors, facility managers, and industrial clients across Ontario. Many CSC LED fixtures qualify for Save on Energy Instant Discount rebates, applied directly on your MarsLED invoice.

  • Canadian-owned manufacturer with proven performance
  • DLC® listed products eligible for utility rebates
  • Designed for warehouses, retail, offices, and industrial spaces
  • Extensive product line (HB8, LHB04, PLP, PLS, ST series)
  • Backed by MarsLED expert support & Ontario-wide distribution

• View all CSC LED products
• Explore Save on Energy eligible lighting
• Use our LED Energy & Rebate Calculator
